Product Features
- High-efficient scroll compressor Copeland / Sanyo / Daikin.
- Split model design to better avoid freezing problem. Automatic anti-freezing protection by detecting system water temperature.
- R410A or R407C or R417A refrigerant.
- Base frame external panels made of polyester powder coated steel or stainless steel.
- Reverse cycle valve.
- Compact structure and sound control design.
- Water side equipped with efficient tank type heat exchanger.
- Automatic anti-freeze and defrosting function.
- Careful protection functions as high pressure. low pressure, overheating, overload, anti-freezing, phase order, discharge temp, etc.
- General testing and operational test carried out for every unit before package in the factory
Split air source heat pump options
We provide OEM and ODM services
Stainless steel casing
The heat pump cover produce with stainless steel casing can protect from rust, special by seaside installation.
Addon bottom heater
With eelctrical bottom heater tap by bottom of the air source heat pump, it avoid freezing of heat pump.
Addon ABB soft starter
We can install ABB soft starter for your heat pump, the unit start more smoothly from 0 to rated voltage.
Add on wifi controller
With wifi controller you can set the heat pump by telephone, with the code it more conventional for our life.
Main Components
Compressor
Our products adopts America Copeland scroll compressor for bigger heat pump and Panasonic compressor for smaller ones,, special designed for heat pump, working high efficiency.
Electronic expansion valve
With branded Sanhua expansion valve and combine with our company’s control system, we have developed a special electronic expansion controller that uses digital technology to adjust the refrigerant according to temperature factors to achieve the best flow rate effect and achieve higher COP.
Electrical control system
With project control function, it can easily control the circulating pump, water compensation, water supply, auxiliary electric heating, PID automatic defrost. Users can set different parameters according to different project needs, and automate the entire system.
Shell and tube heat exchanger
Linsam heat pump adopts high-efficiency shell and tube heat exchanger, the heat exchange area is 3.7 times that of bare tube, its unique design and compact spiral structure of the heat
exchanger ensures the full heat exchange of the refrigerant.
Comparison of different heating method
Compared electric heater, the heat pump cost only 25% can produce 1 unit heating, while electric heater need 100% power consumption.
Technical Parameters
| Model | TAN-03S | TAN-05S | TAN-06S | TAN-10S |
|---|---|---|---|---|
| Cooling capacity kW | 7.5 | 13.3 | 15.6 | 27.2 |
| Input power kW | 2.55 | 4.45 | 5.3 | 8.74 |
| Heating capacity kW | 8.4 | 15 | 17.8 | 32.6 |
| Input power kW | 2.55 | 4.45 | 5.2 | 9.38 |
| Heating capacity kW | 5.8 | 9.7 | 11.2 | 20.5 |
| Input power kW | 2.5 | 4.3 | 4.8 | 8.9 |
| Cooling running current A | 12.5/4.5 | 7.79 | 8.6 | 15.6 |
| Heating running current A | 13.8/4.8 | 8.4 | 9.2 | 16.8 |
| Max running current A | 17/8 | 12 | 16 | 24 |
| Power source | 220V/380V/50HZ | 380V/3N/50HZ | 380V/3N/50HZ | 380V/3N/50HZ |
| Noise level dB(A) | <55 | <58 | <60 | <64 |
| Outdoor unit Up fan W × D × H mm | 670*640*820 | 810*780*1050 | 1390*670*820 | 1450*780*1050 |
| Side fan W x D x H mm | 830*310*710 | 830*310*1260 | 1300*420*1245 | -- |
| Unit weight kg | 120 | 155 | 170 | 245 |
| Indoor unit W × D × H mm | 370*200*450 | 500*260*700 | 500*260*700 | 500*260*700 |
| Unit weight kg | 10 | 12 | 14 | 25 |
| Working temp range ℃ | -15℃-43℃ | -15℃-43℃ | -15℃-43℃ | -15℃-43℃ |
*Test conditions:
1.Cooling: Air source side DB/WB is 35℃/–, inlet water temp 12℃, outlet water temp 7℃.
2.Heating(1): Air source side DB/WB is 7℃/6℃, inlet water temp 40℃ outlet water temp 45℃.
3.Heating(2): Air source side DB/WB is -12℃/-14℃, inlet water temp 40℃, outlet water temp 45℃.
